Slow internet speed issue

Hello,

I run a server with Astaro Security Gateway V 7.505 and i noticed that my internet speed is about 20 Mbps slower than it is supposed to be. My kind of internet contract is for 30 Mbps in download and as soon as the cable modem (Motorola Surfboard SB5101E) is connected to the server than my internet speed over the lan is just 10 Mbps (9.8 to be exact checked with speedtest.net). My first feeling was that there was something wrong with the network card. These are steps i followed:

Changed between 3 different NIC - All 3 supporting 10/100 Mbps, nothing changed

Checked the cable between the modem and the NIC on the server - OK, Cat 5e, the right one


Checked as far as i could via the GUI for possible bandwidth filters or limitations - didn't find any that i am aware of

Keeping in mind also that:

Connecting the laptop directly to the modem, resulted in the correct speed - so not an ISP related issue

The NIC that communicates with the modem is in auto-neogotiation by default and forcing it to 100 Mbps full-duplex didn't help

Internal LAN traffic over the other NIC runs fine at 100 Mbps.

I am out of ideas...so any suggestions or other checks that i could perform are more than wellcome.

Thanks


This thread was automatically locked due to age.
Parents
  • run>cmd>netstat/a

    sound like your server box is possibly hogging your bandwidth...good old SQL does that its called injections [:(] Hope you have image backup if it is.

    Isolate it separately from the lan. Try speedtest.net with your box from lan and see what you get. It's either that or your settings in the Astaro download and upload speeds are incorrect resulting in bottleneck.

    I'm sure your LAN card can burst at 1gig on cat5e up and down Internally but Externally
    speedtest.net (caching OFF!) will give you correct numbers to convert to Astaro.

    External (WAN) Total available uplink bandwidth: 5120 kbits/sec 5meg up example
    Total available downlink bandwidth: 20480 kbits/sec  20meg down

    Edit Internal Total available uplink bandwidth: 1024000 kbits/sec  1 gig 10/100/1000 cards
    Total available downlink bandwidth: 1024000 kbits/sec

    1024=1m per second on speedtest.com X90% for QOS.

    Just remove QOS then try it.

    If you still have problems remove everything.. if that wont work reinstall from scratch or replace hardware. Check ram with test.
    M
Reply
  • run>cmd>netstat/a

    sound like your server box is possibly hogging your bandwidth...good old SQL does that its called injections [:(] Hope you have image backup if it is.

    Isolate it separately from the lan. Try speedtest.net with your box from lan and see what you get. It's either that or your settings in the Astaro download and upload speeds are incorrect resulting in bottleneck.

    I'm sure your LAN card can burst at 1gig on cat5e up and down Internally but Externally
    speedtest.net (caching OFF!) will give you correct numbers to convert to Astaro.

    External (WAN) Total available uplink bandwidth: 5120 kbits/sec 5meg up example
    Total available downlink bandwidth: 20480 kbits/sec  20meg down

    Edit Internal Total available uplink bandwidth: 1024000 kbits/sec  1 gig 10/100/1000 cards
    Total available downlink bandwidth: 1024000 kbits/sec

    1024=1m per second on speedtest.com X90% for QOS.

    Just remove QOS then try it.

    If you still have problems remove everything.. if that wont work reinstall from scratch or replace hardware. Check ram with test.
    M
