experiencing remote vpn subnets partially inaccessible on a couple different xg105w's for site to site vpn connections with the same cisco asa5520 after updating from SFOS 16.05.8 MR-8 to SFOS 17.0.0 GA. ipsec connections page will show yellow status for the connection when this happens. connections are main mode rekeying allowed with phase1 & phase2 aes256 / sha1 + dh5 (working on encryption upgrade) dpd disabled. Power cycling xg may resolve the issue for a very short time and then it recurs indefinitely. screenshots below are from vpn >> ipsec connections >> name >> connection detail. I took the easy way out due to time constraints and rolled firmware back to 16 which clears up the problem and retains good status on all the subnet mappings.
