IPSec Traffic uses wrong port

Do you have a Ipsec Route? support.sophos.com/.../KB-000035839

We've had this issue, too.

Strange here, is we faced it only after Tunnel re-connects. Needed to add SNAT and IPSEC Routes. manually on CLI.

You probably need this commands:

system ipsec_route show

system ipsec_route add net 10.1.2.0/255.255.255.0 tunnelname YourName_Tunnel

show advanced-firewall

set advanced-firewall sys-traffic-nat add destination 10.1.2.0 netmask 255.255.255.0 snatip 192.168.1.2 (this is your firewall's LAN Interface, it needs to be part of the IPSEC Tunnel Networks)

Hi,

I will check. But have to wait for the ssh access from the customer..

I never added the ipsec route manually..

Regards

Daniel

yes, it's not that usual to do that manually. e.g. in Sophos UTM this was also not required.

Hi DanielR: The other possibility which I can think of is SD-WAN has higher route precedence on this XG and any SD-WAN rule for the source  IP or network is present with destination Any to route Internet traffic from a specific ISP - in this scenario as well traffic will be routed via SDWAN rule with WAN interface.

docs.sophos.com/.../RoutingSDWANPolicyRoutesMigrated.html

I just needed this rule system ipsec_route add net 10.1.2.0/255.255.255.0 tunnelname YourName_Tunnel

Resolved my issue.

Regards

Daniel

good to hear it's solved. You need the SNAT if the XG itself needs to access hosts on the other side of the IPSEC. for example Active Directory Servers, DNS Servers to forward to etc.
