Creating Trunk port on XG

leo hamel

Hi all

i have XG firewall with some interfaces, each interface has its own DHCP and NAT rules connecting them and everything is fine

i am trying to install additional hardware port and configure it as trunk for all of the subnets i have to pass it to a switch located in another suite

i am assuming the current setup:

lets say i have 3 ports, 2 existing DHCP ranges for interface 2,3



create the untagged vlan (native vlan) and assign it to the new hardware with DHCP range

create vlan 2 and assign it to the same port and give it the DHCP range of interface 2

create vlan 3 and assign it to the same port and give it the DHCP range of interface 3

please correct me if am wrong
